  • Triple 5.6" Rack Mountable LCD Monitors V-R563P Marshall Electronics
  • Triple 5.6" Rack Mountable LCD Monitors V-R563P Marshall Electronics
  • Triple 5.6" Rack Mountable LCD Monitors V-R563P Marshall Electronics
  • Triple 5.6" Rack Mountable LCD Monitors V-R563P Marshall Electronics
  • Triple 5.6" Rack Mountable LCD Monitors V-R563P Marshall Electronics
  • Triple 5.6" Rack Mountable LCD Monitors V-R563P Marshall Electronics
  • Triple 5.6" Rack Mountable LCD Monitors V-R563P Marshall Electronics
  • Triple 5.6" Rack Mountable LCD Monitors V-R563P Marshall Electronics
  • Triple 5.6" Rack Mountable LCD Monitors V-R563P Marshall Electronics
  • Triple 5.6" Rack Mountable LCD Monitors V-R563P Marshall Electronics
  • Triple 5.6" Rack Mountable LCD Monitors V-R563P Marshall Electronics

    • Triple 5.6" Rack Mountable LCD Monitors V-R563P Marshall Electronics

    Marshall Electronics

    $150.00
    Write a Review
    SKU:
    mx1_254244214148_6BCD200F72224E778B81542
    UPC:
    109954706995
    Condition:
    Used
    Width:
    14.0 (in)
    Height:
    12.0 (in)
    Depth:
    10.0 (in)
    Adding to cart… category.add_cart_announcement

    Product Description

    Up for sale is a triple 5.6" rack mountable LCD monitors that is manufactured by Marshall Electronics. Item listed is in used condition with tape residue on 2 screens.



    The V-R563P is a rack mounted unit that has three independently controlled 5.6" active matrix LCD panels with active loop through feature. These 5.6" panels have 960 x 234 pixels producing a true high resolution image. This unit also has a unique feature that allows it to tilt up or down up to 90 degrees for optimum viewing angle or access to cabling. The unit fits into an EIA standard 19" rack. It takes up 3 rack-units high. Each of the three screens has a built-in color bar generator and front-panel picture controls. Each screen has two composite video inputs and outputs and a 3 color tally system.

    Each monitor has 2 BNC composite video inputs and outputs. If no input signal is detected, the monitor shows a blue screen.
    Color, Tint, Brightness and Color controls are mounted on the front panel for each monitor individually.
    Each monitor has a color-bars generator built in. Additionally, the monitors automatically detect NTSC and PAL signals.
    The Marshall V-R series is unique in that the monitors each have the ability to tilt up to 90 degrees up or down while rack mounted. This feature not only gives the user a perfect viewing angle but it also gives access to the cabling behind the unit without having to walk around the rack.



    EC3-4
