Product Description
Up for sale is a compressor that is manufactured by Red Dot. Item listed is in used condition. Unable to test must sell as is and as a core for parts and or repair.Product Specifications:
- Bore: 1.378 in. (35mm)
- Stroke: 1.13 in. (28mm)
- Displacement per Revolution: 8.42 cu. in. (138cc)
- Number of Cylinders: 5
- Maximum Allowable Continuous R.P.M.Normal Operating Conditions): 5,000
- Refrigerant: R 134A
- Oil (PAG): 7 fl. oz. (207cc)
- Weight: 11.24 lbs (5.1 kg)
- Rotation: Clockwise
- Sanden Part No.: 4537, 6634, 4269
- Voltage: 24
- Sanden Model Type: SD5H14
- Mount Type: Ear
- Head Type: K
- Head Fitting Position: Horizontal O-Ring
- Head Fitting Size: 3⁄4 x 7⁄8
- Cubic Inches: 8.4
- Clutch Type: 5 1⁄4” (132mm) A2 Groove
- Gauge Line: 40mm
- Connector Type: Bullet
- No. of Wires: 1
- Clutch Shaft Type: Key
