Product Description
Up for sale is a genuine Dana Spicer 6-4-4551-1 Transfer Case End Yoke. This heavy-duty steel driveline component mounts to a compatible splined transfer-case or PTO output and provides the connection point between the rotating output shaft and driveshaft universal joint. As the shaft rotates, the yoke transfers torque into the driveline while the universal-joint connection allows the driveshaft to operate through changing angles caused by vehicle movement and drivetrain geometry.
- Joint Yoke is in new old stock condition.
- Item has rust due to being in storage for a long period of time.
Features & Specifications
- Brand: Dana Spicer
- Part Number: 6-4-4551-1
- Alternate Number: 6445511
- NSN: 2520-01-289-5550
- Type: Transfer Case / PTO End Yoke
- Series: 1710
- Material: Steel
- Yoke Style: Half Round
- Spline Count: 10
- Spline Major Diameter: 2.750"
- Hub Diameter: 3.500"
- Length Through Splined Hole: 3.000"
- Centerline to End of Hub: 5.750"
- Yoke Bearing Dimension: 1.938"
- Outside Yoke Dimension: 6.190"
- Joint Angle: 22°
- Spline Type: Non-Involute
Compatibility
A driveline supplier specifically lists this yoke for FABCO TC-142, TC-143, TC-1702 and TC-270 transfer cases.
